TOXFREE ZH H07Z-K
Description
Flexible and halogen free (LSZH) power cable for public places.
TOXFREE ZH H07Z-K is a flexible cable for fixed and protected installations. It is highly recommended for use in public places such as: hospitals, schools, museums, airports, bus terminals, shopping malls, offices, laboratories, etc. Not suitable for wet places or immersed.
TOXFREE ZH H07Z-K cable performance
Electrical performance
Low voltage 300/500 V · 450/750 V.
Rated Voltage: ES05Z1-K/H05Z1-K (up to 1 mm2 ): 300/500 V.
H07Z1-K (from 1,5 mm2 onwards): 450/750 V.
Standard
EN 50525-3-31 / UNE 211002
Approvals
AENOR / HAR / CE / RoHS
CPR Construction Products Regulation
B2ca-s1a, d1, a1
Thermal performance
Maximum conductor temperature: 70ºC.
Maximum short-circuit temperature: 160ºC (max. 5 s).
Minimum service temperature: -40ºC (fixed and protected installations).
Fire performance
Flame non-propagation based on EN 60332-1 and IEC 60332-1.
Fire non-propagation according to EN 60332-3 / IEC 60332-3 and EN 50399.
LSHF (Low Smoke Halogen Free) based on EN 60754-1 and IEC 60754-1.
Low smoke emission based on EN 61034 and IEC 61034: Light transmittance > 80%
Low corrosive gases emission based on EN 60754-2 and IEC 60754-2.
Reaction to fire CPR B2ca-s1a, d1, a1, according to EN 50575.
Mechanical performance
Minimum bending radius: x5 cable diameter.
Chemical performance
Chemical & Oil resistance: Acceptable.
Other
Meter by meter marking.
Installation conditions
In conduit.
Applications
Domestic use.
Electric panel wiring.
Public places.
TOXFREE ZH H07Z-K cable design
Conductor
Electrolytic annealed copper, class 5 (flexible), based on EN 60228 and IEC 60228.
Insulation
LSZH, type EI5 according to EN 50363-5.
The standard identification of insulated conductors is the following:
Blue RAL 5015
Brown RAL 8003
Black RAL 9005
Red RAL 3000
Green/yellow RAL 6018 / 1021
Gray RAL 7000
White RAL 9010
Other colors available on request.
LOW VOLTAGE 450/750V
Maximum service temperature: 90ºC.
Dca -s1b, d1, a1
Flame non-propagation based on EN 60332-1 and IEC 60332-1
Domestic use/ Electric panel wiring / Public places
In conduit
Technology
1. Conductor
Electrolytic copper, class 5 (flexible), based on EN 60228 and IEC 60228.
2. Insulation
LSZH, type EI5 according to EN 50363-5.
The standard identification of insulated conductors is the following:
Blue RAL 5015
Brown RAL 8003
Black RAL 9005
Red RAL 3000
Green/yellow RAL 1021 / RAL 6018
Grey RAL 7000
White RAL 9010Other colors available on request.
Cable Specifications
-
Chemical
Oil resistance: Acceptable.
FIRE PERFORMANCE
- Flame non-propagation based on EN 60332-1 and IEC 60332-1
- Low corrosive gases emission according to IEC 60754-2
- Low smoke emission according to EN 61034 and IEC 61034: Light transmittance > 80%.
- Low smoke halogen free according to IEC 60754-1
- Reaction to fire CPR: Dca-s1b, d1, a1 according to EN 50575 (see cross- section).
MECHANICAL PERFORMANCE
- Minimum bending radius: x5 cable diameter.
ELECTRICAL PERFORMANCE
- LOW VOLTAGE 300/500 V
- OW VOLTAGE 450/750 V
THERMAL PERFORMANCE
- Maximum service temperature: 70ºC.
- Maximum short-circuit temperature: 160ºC (max. 5 s).
- Minimum service temperature: -40ºC (fixed and protected installations)
APPROVALS
- AENOR
- CE
- HAR
- RoHS
OTHERS
- Meter by meter marking. (from 10mm2 onwards)
BASED ON
- EN 50525-3-31
- UNE 211002
CONSTRUCTION PRODUCT REGULATION
- B2ca s1a, d1, a1
APPLICATIONS
- Domestic use.
- Electrical panel wiring.
- Public places.
INSTALLATION CONDITIONS
- In conduit.
