The TOXFREE ZH YMz1Kf safety cable is LSHF. It doesn't release any harmful or corrosive gasses in the case of a fire, protecting humans and electronic devices from potential harm. It is therefore strongly advised for usage in public settings like hospitals, schools, museums, bus terminals, airports, shopping centers, offices, labs, etc.

Performance of the TOXFREE ZH YMz1Kf cable

Electrical functionality

MINIMUM VOLTAGE 0,6/1kV

Typical

UNE 21123-4 and IEC 60502-1

Acceptances

CE, RoHS, KEMA KEUR, SEC, and AENOR

Regulation of Construction Products, or CPR

B2ca s1a, d1, a1 or, depending on the cross-section, Cca s1a, d1, a1

Thermal efficiency

90ºC is the maximum conductor temperature.

250ºC is the maximum short-circuit temperature (maximum 5 s).

-40ºC is the minimum service temperature for shielded and permanent installations.

-0ºC is the minimum temperature required for handling and installation.

Performance of fire

According to EN 60332-1/IEC 60332-1, flames do not spread.

In accordance with EN 60332-3/IEC 60332-3 and EN 50399, fire does not spread.

Low Smoke Halogen Free, or LSHF, is based on IEC 60754-1 and EN 60754-1.

According to UNE-EN 61034 and IEC 61034, low smoke emission is defined as light transmittance > 80%.

low emissions of corrosive gases in accordance with EN 60754-2/IEC 60754-2.

In accordance with EN 50575, the response to fire CPR is either B2ca s1a, d1, a1 or Cca s1a, d1, a1 (see cross-section).

Performance of mechanical systems

A minimum cable diameter of x5 is required for bending.

Medium severity AG2 impact resistance.

Performance of the environment

Resistance to chemicals and oil: Acceptable.

In accordance with EN 50618, UV resistant.

Resistance to water: AD8 Submersion.

Other

marker from meter to meter.

Conditions of installation

Outside.

buried.

in a conduit.

Uses

industrial use.

public areas.

Packing

available in drums and rolls (100 m in length).

Design of the TOXFREE ZH YMz1Kf cable

The conductor

Class 5 (flexible) electrolytic annealed copper conductor in accordance with EN and IEC 60228.

Insulation

IEC 60502-1 classifies cross-linked polyethylene as type XLPE, while HD 603 classifies it as type DIX-3.

In accordance with HD 308, insulated conductors are typically identified as follows:

One Natural

Two times Brown + Blue

3 G Green/Yellow + Brown + Blue

Three x Black + Grey + Brown

(reduced cross-section) 3 x + 1 x Brown + Black + Grey + Blue

4 G: Green/Yellow + Black + Grey + Brown

Four times: Brown, Black, Grey, and Blue

5 G Green/Yellow + Brown + Black + Grey + Blue

6 G or moreBlack digits plus green/yellow

External sheath

Polyolefin outer sheath for Low Smoke Halogen Free (LSHF), type ST8 in accordance with IEC 60502- 1 and type DMZ-E in accordance with UNE 21123-4. The color green.
